Designed and manufactured according to JB/T 2603 electric single beam crane, it can hoist goods in factories, warehouses, yards and other places, and it is forbidden to use inflammable and explosive environments in dangerous places
Lifting limit switch: Prevent the hook out of control when it has been lifted to the top position
Traveling limit switch: Stop the crane traveling smoothly when travel to the rail ends
Overload limiter: Prevent for the overload
Wire rope guide: Align the wire rope neatly on the reel to prevent the wire rope from messing and overlapping
We have the short circuit protection, emergency switch, interlock protection, overload protection, loss of voltage protection, grounding protection and voice-activated alarm lights and other safety protection devices
| Lifting capacity | t | 1 | 2 | 3 | 5 | 10 |
| Span | S(m) | 3~15 | 3~15 | 3~15 | 3~15 | 3~15 |
| Lifting height | m | 6~18 | 6~18 | 6~18 | 6~18 | 6~18 |
| Lifting speed | m/min | 0.8/8 | 0.8/8 | 0.8/8 | 0.8/8 | 0.7/7 |
| Trolley speed | m/min | 20 | 20 | 20 | 20 | 20 |
| Crane speed | m/min | 20 | 20 | 20 | 20 | 20 |
| Work duty | A3 | A3 | A3 | A3 | A3 | |
| Track type | P24 | P24 | P24 | P24 | P24 |
